The block size and the speed rate could be changed.
That is provide the most compatibility with transceivers of different manufactures. The programmer writes data changes with a block size of 8 bytes and a clocking speed on 10kHz for default. The hardware is made with the conditions for compatibility and security of memory chips and control chip, as well as stable power supply of the transceiver circuit. That means all available memory pages of the transceiver could be read and write with special permissions. The programming boards support all address spaces of transceivers (for example: A0H, A2H). SFPTotal programming boards are designed in accordance with MSA SFF specifications, support the GBIC, SFP, SFP +, XFP and QSFP transceivers, and are also able to successfully reprogram the modules of most manufacturers. More information about SFPTotal devices can be get on SFPTotal Wiki.
EEPROM PROGRAMMER WINDOWS 10 SERIAL
Sometimes for PC under OS Windows is needed a system reboot to get stable work of virtual serial port driver.
EEPROM PROGRAMMER WINDOWS 10 SOFTWARE
SFPTotal Wizard software will detect a programming board automatically when a device is connected to PC. The device does not need special settings. The programming board is based on proprietary protocol SFPTotal and operating through official software which provides an interface for access to main features and opportunities of device.
Download and run a software SFPTotal Wizard.A new device will be detected by operation system at first connection of the board. The programming board connects to PC using Micro USB cable included into the kit. The devices support the reprogramming of transceivers with DDM, including transceivers with write protection.ĭevices are made without enclosures to provide free access to controls and jumpers of power plans, which are necessary for programming some passive and active optical cables. SFPTotal programmers are designed for coding GBIC, SFP, SFP+, XFP and QSFP transceivers, including SFP RJ45, DAC/AOC and help to ensure compatibility with network switches of popular brands.
